| 产品 |  PBR-M2移除请选择产品型号添加 | 请选择产品型号添加 | 请选择产品型号添加 | 请选择产品型号添加 |
|---|---|---|---|---|
| IEEE Standard | 协议模式IEEE 802.11n, IEEE 802.11g, 802.11b,IEEE802.11ac , IEEE802.11a, IEEE 802.3,IEEE 802.3u |
|||
| CPU | MTK MT7621A解决方案,主频高达880MHz |
|||
| Flash | SPI FLASH 16/32MB (最高支持32MB) |
|||
| USB Port | 1*USB 3.0 port 1*USB 2.0 port |
|||
| RAM | 内存DDR3 RAM 256/512MB (最高支持512MB) |
|||
| WAN | 1*10/100/1000Mbps WAN port(Auto MDI/MDIX) |
|||
| LAN | 4*10/100/1000Mbps LAN port(Auto MDI/MDIX) |
|||
| Frequency | 工作频段 2.4GHz & 5GHz |
|||
| Wireless Speed | 无线速率最大支持1200Mbps |
|||
| Antenna | 天线 4 * 5dBi 全向天线 |
|||
| Wireless Repeater | ||||
| SATA Port | ||||
| TF-Card Slot | 1*TF卡 |
|||
| SIM Card Slot | ||||
| Battery | 电源输入DC 12V/2A |
|||
| I2S / PCM | ||||
| UART | UART: 1 * UART |
|||
| Button | Reset/WPS按钮；触摸按钮 LED灯按钮开关 |
|||
| Size | ||||
| Operating System | 网络接入方式PPPoE拨号、动态IP、静态IP 工作模式为Router和AP |
|||
| Firewall / Security | 防火墙(IP Address Filter/MAC Address Filter/ Domain Filter) |
|||
| Port Fowarding / DMZ / uPNP | 端口转发(Virtual Server, Port Triggering, UPnP, DMZ) |
|||
| 3G / LTE |
